PRODUCT DESCRIPTION
Model: YFSDB-1
Scheme:
Master chip: 1080p: Ingenic T31ZL/2K: Ingenic T31ZX (Note: The chip will be replaced due to product upgrades without notice)
Image sensor: SC2335/SC233A (Note: Sensor will be replaced due to product upgrades without notice)
Audio video:
Pixel: 200W 1080P resolution
Video encoder: Main stream (HD) : H.265; Substream (SD) : H.264
Video bitrate: Main stream (HD) : 1Mbps; Substream (SD) : 384Kbps
Video frame rate: Main stream (HD) : 1080P@15fps; Substream (SD) : VGA@20fps
Lens: Focal length: 3mm; Aperture: F2.0
Vision Angle: Diagonal 160 °
Video codec standard: H.265/H.264
Voice intercom: Supports bidirectional voice intercom and echo cancellation
Audio input / output: Number 1 Mic / Number 1 Speaker
Indicator light: Green/white dual-color indicator. White is the device status indicator, and green is the charging indicator
Infrared lamp: Six 850nm infrared lamps
Night vision mode / distance: IR-CUT automatically switch / Maximum night vision distance 5m
Wireless connection: 2.4 GHz Wi-Fi IEEE 802.11 b/g/n
Motion detecting: Supports PIR body movement detection
Message function: Supports message leaving function
Ticktok:
Supports indoor Ticktok: RF 433MHz
Gateway:
Gateway: Supported
Value-added function:
Tuya cloud storage: Supports event video
Amazon Alexa: Supported
Google assistant: Supported
Power supply:
DC 5V1A
18650*2 Lithium battery, Rechargeable battery, non-removable, charge protected
Capacity: 5200mAh
Battery duratio: 4~6 months (10 times a day) (related to the use environment and scene, subject to actual test)
Environment:
Temperature: -0°C ~ 45°
Humidity: 10 ~ 95% without condensation
Memory:
Support the maximum 128GB TF card and cloud storage
Waterproof grade: IP66
Material: Plastic housing
Dimension and package:
product dimension: 249*184*49mm
product weight:0.65KGS
package: 28pcs/carton
carton size 51*38*36.5CM
19KGS/carton
